An intermediary device for wireless communication between the lighting controllers mounted in LED luminaires and optional measuring and control devices, and the IT monitoring and control system.
2.4 GHz secure Thread protocol communication with controllers
two independent Thread communication paths
communication with measurement devices via wired interface RS-485
communication with control devices through binary signal inputs and relay outputs
communication with the IT system via 2G/3G/4G(LTE) mobile network or WAN wired interface
Mechanical data
Mounting
on DIN TS-35 rail
Operating temperature range [°C]
-40 ... +70
Body
plastic (PC+ABS)
Type
LTE Customer SIM Operator, LTE LUG SIM Operator
Electrical data
Power
24V DC
Includes light source
no
Wireless communication
yes
Wireless communication standard
IEEE 802.15.4, Thread, 2,4 GHz; 2G/3G/4G(LTE)
Wired communication
yes
Wired communication standard
Ethernet, RS-485, signal binary inputs, relay outputs
General data
Additional information
Intermediary device for communication between a network of radio-mesh lighting controllers and an IT-based monitoring and control system, and between measuring and control devices and an IT-based monitoring and control system
Warranty
5 years
Dimensions
Dimensions [mm] LxWxH
143x91x63
X
Available variants
Compare
Code
Type
Other remarks
Wireless communication standard
Wired communication standard
Power supply via safety transformer
Operating temperature range [°C]
790030.101
Global version
IEEE 802.15.4, Thread, 2,4 GHz; 2G/3G/4G(LTE)
Ethernet, RS-485, signal binary inputs, relay outputs
-40 ... +70
790030.101.01A
LTE LUG SIM Operator
MOUNTING KIT WITHOUT POWER SUPPLY (2pcs Thread antenna, 2pcs LTE antenna, 4pcs antenna holder for DIN rail, 4pcs antenna adapter 1m)
IEEE 802.15.4, Thread, 2,4 GHz; 2G/3G/4G(LTE)
Ethernet, RS-485, signal binary inputs, relay outputs
-40 ... +70
790030.101.01B
LTE Customer SIM Operator
MOUNTING KIT WITHOUT POWER SUPPLY (2pcs Thread antenna, 2pcs LTE antenna, 4pcs. antenna holder for DIN rail, 4pcs antenna adapter 1m)
IEEE 802.15.4, Thread, 2,4 GHz; 2G/3G/4G(LTE)
Ethernet, RS-485, signal binary inputs, relay outputs
-40 ... +70
790030.101.02A
LTE LUG SIM Operator
MOUNTING KIT WITH POWER SUPPLY (24V DC/15W 110-240V AC adapter, 2pcs. Thread antenna, 2pcs LTE antenna, 4pcs DIN rail antenna holder, 4pcs 1m antenna adapter)
IEEE 802.15.4, Thread, 2,4 GHz; 2G/3G/4G(LTE)
Ethernet, RS-485, signal binary inputs, relay outputs
-40 ... +70
790030.101.02B
LTE Customer SIM Operator
MONITORING KIT WITH POWER SUPPLY (24V DC/15W 110-240V AC adapter, 2pcs Thread antenna, 2pcs LTE antenna, 4pcs antenna holder for DIN rail, 4pcs antenna adapter 1m). antenna adapter 1m)
IEEE 802.15.4, Thread, 2,4 GHz; 2G/3G/4G(LTE)
Ethernet, RS-485, signal binary inputs, relay outputs
-40 ... +70
790030.101.03A
LTE LUG SIM Operator
MOUNTING KIT WITH POWER SUPPLY AND LAST GASP 230V FUNCTION (power supply 24V DC/60W 110-240V AC, relay 2pcs. Thread antenna, 2pcs LTE antenna, 4pcs antenna holder for DIN rail, 4pcs antenna adapter 1m)
IEEE 802.15.4, Thread, 2,4 GHz; 2G/3G/4G(LTE)
Ethernet, RS-485, signal binary inputs, relay outputs
-40 ... +70
790030.101.03B
LTE Customer SIM Operator
FIXING KIT WITH POWER SUPPLY AND LAST GASP 230V FUNCTION (power supply 24V DC/60W 110-240V AC, Last Gasp 230V, 2pcs Thread antenna, 2pcs LTE antenna, 4pcs antenna holder for DIN rail, 4pcs. antenna adaptor 1m)
IEEE 802.15.4, Thread, 2,4 GHz; 2G/3G/4G(LTE)
Ethernet, RS-485, signal binary inputs, relay outputs
-40 ... +70
790030.101.04A
LTE LUG SIM Operator
MONITORING KIT WITH POWER SUPPLY AND LAST GASP 110V FUNCTION (power supply 24V DC/60W 110-240V AC, 2pcs. Thread antenna, 2pcs LTE antenna, 4pcs antenna holder for DIN rail, 4pcs antenna adapter 1m)
IEEE 802.15.4, Thread, 2,4 GHz; 2G/3G/4G(LTE)
Ethernet, RS-485, signal binary inputs, relay outputs
-40 ... +70
790030.101.04B
LTE Customer SIM Operator
FIXING KIT WITH POWER SUPPLY AND LAST GASP 110V FUNCTION (power supply 24V DC/60W 110-240V AC, Last Gasp 110V, 2pcs Thread antenna, 2pcs LTE antenna, 4pcs antenna holder for DIN rail, 4pcs antenna adaptor 1m)
IEEE 802.15.4, Thread, 2,4 GHz; 2G/3G/4G(LTE)
Ethernet, RS-485, signal binary inputs, relay outputs
-40 ... +70
